Type PZ160-1 Row drilling machine
Row drilling machine is a large mechanical equipment to drill holes on oil casing; The PZ160-1 row drill machine can drill casings up to 11.5 m with the hole maximum diameter of 16 mm.
Key word:
Category:
Full Set Auto Screen Pipe Production Line
Type PZ160-1 Row drilling machine
Row drilling machine is a large mechanical equipment to drill holes on oil casing; The PZ160-1 row drill machine can drill casings up to 11.5 m with the hole maximum diameter of 16 mm.
Product Introduction
Row drilling equipment is a large-scale mechanical equipment to drill holes on oil casing; PZ160-1 row drilling machine can drill oil casing up to 11.5 meters, the maximum hole diameter can reach 16mm; the clamping device is a pneumatic chuck, which can quickly clamp or loosen the pipe; this equipment adopts PLC + touch screen control, with a high degree of automation.
Equipment parameter
| Equipment model | Number of spindles | Drilling diameter |
| PZ160-1 | 38 | 9.5~16mm |
| Distance between spindles | Spindle speed | Maximum drilling length |
| 203.2~304.8mm | 200~400RPM | 11.5m |
| Pipe diameter | Control system | Power |
| 73~245m | PLC + touch screen | ≈160KW |
